| Device Purpose | Suitable for attaching waterproostrips to various types of sock covers | Power Requirement | Single-phase AC220V,50HZ/60HZ |
| Rated Power | 1.8KW | Air Pressure Requirement | Stable air source of 5kg/cm²(without water vapor) |
| Welding Temperature | 800°C | Heating Protection | 1 set of air pressure switch (The heating tube will not heat up when the air pressure othe air nozzle is lower than 0.3kg/cm²) |
| Welding Speed | 1-18m per minute (digitally controlled) | Operation Mode | Double foot pedals (The left foot controls the up-and-down pressing wheels and two sets of shearing actions,and the right foot controls the rotation of the roller and the action of the hot air gun) |
| Hot Air Gun Specification | 25mm double-row perforated airnozzle orlinear opening air nozzle (optional) | Specification of Upper Pressing Wheel | 25mm*45mm(Silicone wheel) |
| Specification of Lower Pressing Wheel | 25*25mm(Stainless steel) | Control Mode | Controlled by PLC touch screen |
| Lifting Height of the Roller | 0~30mm | Number of Motors | 2 groups (Stepper motors) |
| N.W.(Net Weight) | 125KG | G.W.(Gross Weight) | 170KG(Packed in a wooden case) |
| Frame | Liftable frame | Machine Dimensions(W*L*H) | 1200*530*1520mm |
| Packaging Dimensions(W*L*H) | 1240*670*1620mm |
