| Device Purpose | Applicable to various products withhot air fusion waterproofing | Device Function | Hot air welding/fusion |
| Power Requirement | Single-phase AC220V,50HZ/60HZ | Rated Power | 1.8KW |
| Air Pressure Requirement | Stable air source of 5kg/cm²(without water vapor) | Welding Temperature | 800°C |
| Heating Protection | 1 set of 0.3kg/cm² air pressure switch(The heating tube will not heat up when the air pressure is lower than 0.3ka/cm²) | Welding Speed | 1-22m per minute (digitally controlled) |
| Operation Mode | Double foot pedals (The left foot controls the up-and-down pressing wheels and two sets of shearingactions, and the right foot controls the rotation of the roller and the action of the hot air gun) | Hot Air Gun Specification | 25mm fixed flat-mouthed air nozzle |
| Specification Of Upper Pressing Wheel | 25*58mm(Silicone wheel) | Specification Of Lower Pressing Wheel | 25*58mm(Silicone wheel) |
| Control Mode | Controlled by PLc touch screen | Lifting Height of the Roller | 0~30mm |
| Number of Motors | 2 groups (Digital stepper motor connected to the driver) | N.W.(Net Weight) | 115KG |
| G.W.(Gross Weight) | 150KG | Machine Dimensions (W*L*H) | 1200*600*1800mm |
| Packaging Dimensions (W*L*H) | 1240*670*1620mm |
