| Device Function | Seamless edge wrapping/edge sealing processes for various types of shoes and garments | Device Purpose | Used for various edge-wrapped product |
| Power Requirement | Single-phase AC220V,50HZ/60HZ | Rated Power | 3.5KW |
| Air Pressure Requirement | Stable air pressure of 5kg/cm²(without water vapor) | Air Nozzle Temperature Range | Room temperature to 250'C (lt is recommended that the temperature be below250"°C) |
| Welding Speed | Up to 1 meter per minute | Operation Mode | Double foot pedals (The left footcontrols the up-and-down movement of the wheels,and the rightfoot controls the rotation of the roller) |
| Upper Belt Specification | 420*25mm(High-temperature silicone) | Lower Belt Specification | 420*25mm(High-temperature silicone) |
| Lifting Height of the Roller | 0 to 18mm | Numberof Motors | 2 groups (Digital steppermotors connected to drivers) |
| Machine Dimensions | 1200*657*1650mm | Packaging Dimensions | 1240*700*1500mm |
