QC-860SJ/Q860SJP/QC-860SJ-X Belt gluing /Trimming /Folding machine-Donguan Changqiauto Technologyco.Ltd

Voltage:AC220V 50HZ/60HZ
Power:1.54KW
Air pressure:>4kg/cm²
Gluing width:8-20mm
Welding speed:1-18m/min
Upper belt specification:20*340mm(high-temperature silicone rubber)
Lower belt specification:20*360mm(high-temperature silicone rubber)
Roller lifting height:0-15mm
Welding temperature:50-250°C(upper and lower belts:，50-360°C(air gun temperature independently adjustable)
Operation mode:Large pedal, single-foot two.stage operation
Air gun specification:Fixed 14mm nozzle (can be set to fixed and mobile modes)
Control method:7-inch PLC touch screen visual operation

4/6

QC-860SJ/Q860SJP/QC-860SJ-X Belt gluing /Trimming /Folding machine

Service hotline:

0086-139 2945 8047

Details

Technical Details

Voltage	AC220V 50HZ/60HZ	Power	1.54KW
Air pressure	>4kg/cm²	Gluing width	8-20mm
Welding speed	1-18m/min	Upper belt specification	20*340mm(high-temperature silicone rubber)
Lower belt specification	20*360mm(high-temperature silicone rubber)	Roller lifting height	0-15mm
Welding temperature	50-250°C(upper and lower belts:，50-360°C(air gun temperature independently adjustable)	Operation mode	Large pedal, single-foot two.stage operation
Air gun specification	Fixed 14mm nozzle (can be set to fixed and mobile modes)	Control method	7-inch PLC touch screen visual operation
Number of motors	2 sets (digital stepper motors withdrivers)+1 set(potentiometer speed control)	Heating devices:	4 sets
Upperandlowerwheels	57AM23-G,2 motors	Cutting knife	Brushless motor, 1
N.W(Net weight)	94KG	G.W(Gross weight)	129KG(wooden box packaging)
WLH(Machine size)	12006571200mm	W'L*H (Packaging size)	12407001330mm
